Transmission Holding Fixture

[Indycars]

Sorry to high jack the thread.

Indycars, would you mind sharing the details about that transmission stand? Is it able to hold a full built ready to run trans? I have one I need to rebuild come spring. It's a pain trying to load a transmission's internals while it's sitting in a stack of tires.

Yes, it held my 200-4R trans fully assembled.
.





.
Download the PDF file for the dimensions below:

TransmissionHoldingFixture02.pdf

(93.26 KiB) Downloaded 39 times

.

[Loose Ctrl]

Thank you, sir. That is a really simple yet extremely helpful tool post.
